Ford 1L5Z-2200-AA
Brake Shoes, Rear

The brake shoe servicing process begins with brake drum removal followed by inspection of the rear brake assembly to check for excessive leakage from the rear wheel cylinder and contamination on the brake shoes and linings and minimum thickness above the backing plate or rivets and heat discoloration on the springs and the adjusting lever's contact with the brake adjuster screw must be checked. Mark the positions of the short and long brake shoe retracting springs before you take out these springs. The mechanic needs to disconnect the brake shoe adjusting lever cable before moving on to remove the cable guide then the adjusting lever return spring before extracting the brake shoe adjusting lever and brake shoe adjusting screw spring and finally the brake adjuster screw assembly. The parking brake link spring along with the brake parking spring retainer will separate from the parking brake strut, thus remove the brake shoe anchor pin guide plate, parking brake strut and parking brake lever pin retainer. The brake shoe hold-down springs and pins must be detached first before removing the rear brake shoes and linings. To install the brakes use Silicone Brake Caliper Grease and Dielectric Compound D7AZ-19A331-A (Motorcraft WA-10) or an equivalent silicone compound that meets Ford specification ESE-M1C171-A. The parking brake lever should then be connected to the rear brake shoe and lining with the parking brake lever pin retainer securing it before installing the brake shoe hold-down spring pins and springs. Put in place the parking brake strut then the link spring and spring retainer before adding the short brake shoe retracting spring. Position the brake shoe adjusting lever cable inside the cable guide groove before installing both the retracting spring and cable guide of the long brake shoe. Assume control of the brake adjuster screw assembly for disassembly before adding silicone grease and performing reassembly while following standards that require R or L stamping on the brake adjuster screw socket ends for installation sequence determination. Position the brake adjuster screw assembly followed by installation of the brake shoe adjusting screw spring and correct placement of the brake shoe adjusting lever and all its components. Check the automatic self-adjuster functionality through cable manipulation of the brake shoe adjusting lever while monitoring brake shoe adjuster assembly rotation until it enters the following notch after cable release. Adjustment of brakes should occur before installing the brake drum.

The first step to repair or service parking brake shoes involves checking that the parking brake control is unlocked and then lowering system tension with front parking brake cable and conduit stretch before inserting a 4 mm (5/32-inch) drill bit equivalent retainer. Ground your vehicle after lifting it up properly before unattaching the tire and wheel assembly and removing the rear brake disc. The servicing begins with removing the brake shoe retracting spring and the brake shoe adjusting screw spring and also takes out the brake adjuster screw and the rear brake shoe hold-down springs. The installer should remove the rear brake shoes with linings and inboard brake shoe retracting spring before inspecting all parts for wear and damage which will require replacement if needed. When installing the rear brake shoes and linings with the inboard brake shoe retracting spring use Silicone Brake Caliper Grease and Dielectric Compound D7AZ-19A331-A (Motorcraft WA-10) or equivalent silicone compound which meets Ford specification ESE-MIC171-A at the brake shoe contact point. The brake shoe hold-down springs must be installed next to the brake adjuster screw along with the brake shoe adjusting screw spring and the outboard brake shoe retracting spring. The Brake Adjusting Gauge helps measure rear brake disc drum dimensions and the brake shoes must be set to a 0.5 mm (0.020 inch) reduction relative to this measurement. Before installing the rear brake disc eliminate all foreign substances and corrosive elements, dirt from the mounting points on wheel, wheel hub, brake drum and brake disc. Proper metal-to-metal contact is essential for this step. As the final step install the wheel and tire assembly, apply tension to the parking brake cable system while carefully holding the front parking brake cable alongside the conduit then remove the retainer from the parking brake control before testing the parking brake operation.
