Ford XF5Z-17K835-AAA
Bumper Cover

The front bumper cover maintenance process starts with the removal of its pin-type retainers positioned at the top of the cover. The two screws and the two side marker lamps must be removed at this stage before handling the electrical connectors to place the lamps separate from the mounting surfaces. Move forward to take off both external pin-type retainer elements attached to the bumper cover. Detach the two mud flaps as well as the two fender splash shields by taking out the screws and pin-type retainers. To reach the bolts access the opening in the fender you need to remove each bumper cover bolt which has two at every side. Your next step should be disconnecting the fog lamp electrical connectors when they exist before completing bumper cover removal. Replacement or installation of the new bumper cover requires the same steps to be executed in reverse order.

The procedure for repairing or servicing the front bumper cover starts with upper pin-type retainers removal from the bumper cover followed by disconnecting two screws and two side marker lamps then setting them aside while disconnecting their electrical connectors. The two exterior bumper cover pin-type retainers must be detached from the assembly. The two mud flaps and two fender splash shields should first be removed through the process of pin-type retainer unscrewing followed by removal. Through the fender opening remove the bumper cover bolts which number two on each side. The final step of removing the bumper cover includes disconnecting fog lamp electrical connectors when they are present. Use the opposite order of steps to put on the new bumper cover.

Six lower bumper cover screws.
