Diagram (1 of 1): Fuel System Components

1997 Ford Taurus Fuel System Components Diagram

Enlarge Diagram

Sort by:

Ref No.

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

2
YF1Z-9B007-AB
Shield

3
3F1Z-9092-AA
Strap Assembly - Fuel Tank
Strap
Part Notes: W/Flex Fuel;W/O Flex Fuel
Location: Driver Side
3
3F1Z-9092-AB
Strap Assembly - Fuel Tank
Strap
- Part Notes: W/Flex Fuel;W/O Flex Fuel
- Location: Passenger Side

5

XU5Z-9030-JA
Cap Assembly - Fuel Tank Filler
Filler Cap
MSRP: $34.73 Your Price: $21.87
1
Add To Cart

6
F7DZ-9H307-AB
Sender And Pump Assembly
Fuel Pump Assembly
Part Notes: 3.0 Liter Sohc
6
F7DZ9H307LB
Sender And Pump Assembly
Fuel Pump Assembly
- Part Notes: 3.0 Liter Dohc

7

F6DZ-9276-A
Seal
Fuel Pump Assembly Gasket
MSRP: $19.00 Your Price: $12.28
2
Add To Cart

8
F6DZ-9C385-A
Ring - Retaining
Lock Ring
MSRP: $4.12 Your Price: $2.98
1
Add To Cart

9
F7DZ-9275-AA
Sender Assembly
Sending Unit
Part Notes: 16 Gallon
9
F7DZ9275CA
Sender Assembly
Sending Unit
- Part Notes: 18 Gallon, Before 9/96;18 Gallon, From 9/96

E1PZ-9324-A
Hose Assy
- Part Notes: 3/8" TUBE SIZE - 25 FT. ROLL
- Callout Name: 9324
Your Price: $157.45
View Details

-N802239-S
Retainer - Quick Connect
- Part Notes: (AR-51-A) RETAINER-5/16" TUBE PUSH CONNECT - (8/94)
- Callout Name: 9J279
- Replaced By: -N806191-S1901
MSRP: $50.22 Your Price: $29.25
View Details

-N605770-S2
Bolt - Hex.Head
- Callout Name: N605770-S2
MSRP: $18.75 Your Price: $13.78
View Details

F7DZ-9030-AA
Cap Assy - Fuel Tank Filler
- Fit Note: Taurus
- Callout Name: 9030
- Replaced By: XU5Z-9030-JA
MSRP: $34.73 Your Price: $21.87
View Details

E7DZ-9155-A
Filter Assy - Fuel
- Part Notes: exc. Flex Fuel
- Fit Note: Taurus
- Callout Name: 9155
- Replaced By: YF1Z-9155-CA
MSRP: $33.64 Your Price: $21.18
View Details

-N802241-S
Retainer
- Part Notes: (AR-51) retainer-3/8" tube push connect
- Callout Name: 9J279
- Replaced By: -N806190-S1901
MSRP: $3.25 Your Price: $1.92
View Details

-N802710-S190
Retainer
- Part Notes: (AR-51-C) retainer-6.35 push connect (duck bill)
- Callout Name: 9J279
MSRP: $3.25 Your Price: $1.92
View Details

-390520-S
Clamp
- Callout Name: 390520-S
MSRP: $17.00 Your Price: $9.99
View Details

E1FZ-9B076-B
Seal
- Part Notes: Except E(Flex Fuel),A, DC, DT, K, MA, and ST
- Callout Name: 9B076
- Replaced By: F6TZ-9B076-AA
MSRP: $19.64 Your Price: $12.69
View Details

F8DZ-9J274-AA
Connector
- Part Notes: vapor line connector including yellow clips. , 12V
  vapor line connector including yellow clips. , 24V
  vapor line connector including yellow clips. , Flex Fuel
- Fit Note: 6 Cyl 3.0L, Taurus
- Callout Name: 9K313
MSRP: $25.36 Your Price: $18.63
View Details

-N802429-S100
Hardware - Miscellaneous
- Callout Name: N802429-S100
- Replaced By: -W710790-S437
MSRP: $7.75 Your Price: $4.56
View Details

E1PZ-9324-B
Hose Assy
- Part Notes: 5/16" TUBE SIZE - 25 FT. ROLL
- Callout Name: 9324
Your Price: $77.90
View Details

F75Z-9C052-AA
Sensor Assy
- Fit Note: Taurus
- Callout Name: 9C052
- Replaced By: XS4Z-9C052-AA
MSRP: $132.55 Your Price: $80.55
View Details
