2004 Ford E-350 Super Duty Fuel System Components, Fuel Delivery

Part Notes: F5AB-14A464-AB, mates w/12A697 air charge temp sensor, 2 cavity , Wiring Circuit: 2

Part Notes: 4 cavity, male, Sensor - Catalyst Monitor

Part Notes: 2 cavity, male, Sensor - Cylinder Head Temperature

Part Notes: 3 cavity, male, Lamp - Dome
3 cavity, male, Switch - Inertia (Fuel Pump)

Part Notes: Elbow on front passenger side cylinder head.

Part Notes: Press in Heater hose fitting with 1/4" fitting on the side.

Part Notes: Attaches to back side of water pump. Slides into the 8555. Orings are W704593-S100. Has additional nipple between brackets., 5.4L; With additional water port at rear of engine

Part Notes: Heater hose - underbody return, w/ high output (auxiliary) heater/ac

Part Notes: Dual tube asy - heater body underbody, with heater/ac prep pack,with heater/ac prep pack deluxe
Dual tube asy - heater body underbody, with heater/ac prep pack,with heater/ac prep pack deluxe , ENG.SZ.: 10
Dual tube asy - heater body underbody, with heater/ac prep pack,with heater/ac prep pack deluxe, FROM 13-JAN-2004 , ENG.SZ.: 8

Part Notes: A/C tube assembly , attaches from underhood 19E558 line to 19A990 pressure valve, Diesel engines, with heater/AC prep pack or heater/AC prep pack deluxe (for aftermarket installation of auxiliary heater/AC systems), 3/8" O.D.

Part Notes: Short A/C tube that attaches from the underbody tube to the auxiliary evaporator tube, with high output (auxiliary) heat/AC, 3/8" O.D.

Part Notes: Also serviced in 9B149 Kit, Cutaway/Stripped Chassis/Chassis Cabs, Gas/Gaseous, Unleaded fuel

Part Notes: Frame mounted fuel pump/filter assembly, 6.0L Diesel

Part Notes: Clean air hose Inlet to Turbo - (Navistar ID 274090R91)

Part Notes: M6 x 1.0 x 12 hex head (screw & washer assy.) , midship tank

Part Notes: 4 cavity, male, Switch - Heater A/C Blower

Part Notes: 4 cavity, male (10 gauge), Resistor - Blower Motor (Front)
4 cavity, male (10 gauge), Resistor - Blower Motor (Rear)

Part Notes: #1 in illustration. Supply hose., less high output (auxiliary) heater/ac, attaches from heater core to front of intake manifold
Heater hose - supply, 4.6L/5.4L/6.8L,less high output (auxiliary) heater/ac,less heater/ac prep pack, attaches from heater core to front of intake manifold

Part Notes: A/C low pressure tube asy, All gas engines, with heater A/C prep pack or prep pack deluxe, 3/4" O.D., attaches from under hood 19E558 A/C line assembly to 19752 valve located under LH front door

Part Notes: Hose asy - A/C, with high output (auxiliary) heat/AC,jumper tube attaches from underbody a/c line to auxiliary evaporator outlet

Part Notes: Also serviced in 9034, Cutaway/Stripped Chassis/Chassis Cabs, Diesel

Part Notes: 4 cavity, female, Switch - A/C Pressure Cut Off (Diesel)

Part Notes: 3 cavity, male, Lamp - Headlamp - High/Low Beam (Aero Lamp)

Part Notes: 3 cavity, male, Alternator, except Diesel

Part Notes: Hose asy - heater return, 4.6/5.4/6.8L,less high output (auxiliary) heater/ac,less heater/ac prep pack, FROM 13-JAN-2004

Part Notes: Heater hose - supply, with high output (auxiliary) heater/ac, FROM 10-MAR-2004

Part Notes: Attaches to back side of water pump under intake manifold. Slides onto the 8555. O-rings are W704593-S100., 6.8L

Part Notes: Attach to 9B593 valves on the fuel tank, Diesel

Part Notes: Navistar # 1845794C9* (w300965 is the o-ring), RH (Glow plug harness)

Part Notes: 3 cavity, gold terminals (also reference TSB #07S57), Sensor - Camshaft Position, 7.3

Part Notes: Nipple exiting water pump. O-ring is 1825293C1., 4" straight connector, 7/8 UNF X 5/8 Tube

Part Notes: 72" x 12". Includes 9C121 valve(includes 9039 O'ring) , CNG,Vans/Wagons
72" x 12". Includes 9C121 valve(includes 9039 O'ring) , NGV,Vans/Wagons, extended range

Part Notes: Also serviced in 9G282 frame mtd. fuel pump filter assembly, Diesel, 6.0L

Part Notes: 3 tube(fuel supply/return/vapor) holder clip w/mtg stem. Also serv in 9S296., Cutaway/Stripped Chassis-Gas

Part Notes: (Stripped Chassis/ Cutaway) unleaded gas, throwaway tank

Part Notes: Kit, 12 cavity, male - for terminals contact FCS at 877-682-4276, Sensor - Transmission Range , Wiring Circuit: 12

Part Notes: 5 cavity, female, Motor - Windshield Wiper

Part Notes: 2 cavity, female, Fuel injector, with 4.6, 5.4
2 cavity, female, Fuel injector, with 6.8
2 cavity, female, Horn

Part Notes: 1 cavity, male, Capacitor - Ignition/Radio

Part Notes: 3 cavity, female, Sensor - Manifold Absolute Pressure, Diesel

Part Notes: 1 cavity, male, Switch - Oil Sending Unit

Part Notes: 10 cavity, male, Actuator - Speed Control

Part Notes: Heater hose (supply), #1 in illustration,less a/c and with auxiliary heater prep pack, connects to water pump
Heater hose (supply), #1 in illustration,with high output (auxiliary) heater/ac, connects to water pump
Heater hose (supply), #1 in illustration,with manual a/c and heater/ac prep pack or heater a/c prep pack deluxe, connects to water pump

Part Notes: #2 in illustration - Return hose, less a/c, 5/8" quick connect, BEFORE 13-JAN-2004
#2 in illustration - Return hose, less high output (auxiliary) heater/ac, 5/8" quick connect, BEFORE 13-JAN-2004
#2 in illustration - Return hose, with manual ac and less heater/ac prep pack or less heater/ac prep pack deluxe, 5/8" quick connect, BEFORE 13-JAN-2004

Part Notes: Attaches to back side of waterpump. Slides onto the 8555., 6.8L

Part Notes: Pressed in block behind water pump; O-rings are W704593- S100

Part Notes: Also service fill hose 9047 and vent hose 9170, Cutaway/Stripped Chassis/Chassis Cabs, Gas/Gaseous, Unleaded fuel;Less School Bus Package

Part Notes: Clip 9.0mm & clamp 18mm with tether. Attach fuel supply line to fuel rail., Gas

Part Notes: Junction plate, male (multiswitch), Switch - Power Window/Door Lock

Part Notes: This part presses into the front right manifold next to therm. housing and has one nipple for heater inlet hose

Part Notes: Clip 12.5mm & clamp 18mm with tether. Attach fuel supply line to fuel rail., Gas

Part Notes: Navistar # 1845695C9* (w300965 is the o-ring), LH (Glow plug harness)

Part Notes: 4 cavity, female, Switch - A/C Compressor Clutch Cycling
4 cavity, female, Switch - A/C Pressure Cut Off
4 cavity, female, Switch - Barometric Pressure

Part Notes: 3 cavity, male, Lamp - Headlamp - High/Low Beam - Non-Aero

Part Notes: 4 cavity, female, Switch - Sliding Door Contact

Part Notes: F5AB-14A464-AB, mates w/12A697 air charge temp sensor, 2 cavity , Wiring Circuit: 2
F5AB-14A464-AB, mates w/9F945 solenoid cannister valve, 2 cavity , Wiring Circuit: 2

Part Notes: 7 cavity, female, Switch - Multi-function (steering column)

Part Notes: 4 cavity, male, gold terminals, Sensor - O2 (HEGO/ EGO), 5.4

Part Notes: 8 cavity, female, Motor - Heater/AC Blend Door

Part Notes: 3 cavity, female, Sensor - Delta Pressure Feedback EGR

Part Notes: (AB-116-MA) package of 4, mounts 9A017/9053 support to frame., (Cutaway/Stripped Chassis) aft tank

Part Notes: 2 cavity, female, A/C Compressor Clutch
2 cavity, female, Speaker - Door (Rear)

Part Notes: 2 cavity, female, Motor - Power Window - LH - Front
2 cavity, female, Motor - Power Window - RH - Front

Part Notes: 2 cavity, female, Coil - Ignition, 4.6, 5.4, 6.8
2 cavity, female, Sensor - Camshaft Postion, 4.6, 5.4
2 cavity, female, Sensor - Crankshaft Position, 4.6, 5.4, 6.8

Part Notes: Camshaft position sensor (CKP), 2 pin , Wiring Circuit: 2
Crankshaft position sensor, 2 pin , Wiring Circuit: 2

Part Notes: 2 cavity, male - includes (1) connector (1) boot, (2) terminal pigtails,(2) heat shrink butt connectors, Speed sensor, ABS sensor in rear axle

Part Notes: 16 cavity, male, Test Connector - Diagnostic

Part Notes: Cartridge type - mounts to frame, (Cutaway)

Part Notes: 2 cavity, male, Motor - Windshield Washer Fluid Pump

Part Notes: 2 cavity, male (Tin terminals), Solenoid - Canister Vent
2 cavity, male (Tin terminals), Switch - Brake Pressure, 5.4

Part Notes: 2 cavity, male, Solenoid - EGR Vacuum Regulator

Part Notes: 2 cavity, female, Actuator - Door Lock - Sliding Door

Part Notes: 3 cavity, female, Sensor - Fuel Injection Timing, 6.0, 7.3

Part Notes: 3 cavity, male, Sensor - Brake Fluid Level

Part Notes: 12 cavity, male, Sensor - Transmission Range

Part Notes: 6 cavity, 5 pin to F2UZ-19986-C blower switch

Part Notes: Radiator cooling fan motor - use w/D8BZ 14474-C (male) - Blower motor, 2-pin rectangular connector , Wiring Circuit: 2

Part Notes: 3 cavity, female, Switch - Heater A/C Temperature Control

Part Notes: 2 cavity, male, Fuel injector , Wiring Circuit: 2, Color: Black

Part Notes: 2 cavity, male (10 gauge), Motor - Heater A/C Blower (Front)

Part Notes: 6 cavity, male, Switch - Heater A/C Blower (rear)

Part Notes: Mounts front fuel supply/return/vapor lines (9S273/9S274/9D676). Nylon clip 3 tube holder 52mm wide w/mtg stem., Gas

Part Notes: 2 cavity, male, Switch - Coolant Temperature Sending Unit

Part Notes: 3 cavity, female, Sensor - Accelerator Pedal Position
3 cavity, female, Sensor - Throttle Position
