OEM Ford Freestyle Intake Manifold

Ford Freestyle Intake Manifold Parts and Q&A

• Intake Manifold
  5F9Z-9424-DA
  Q: How to service and repair the upper intake manifold on Ford Freestyle?

  A:

  The upper intake servicing process starts by draining the fluid from the cooling system and disconnecting the battery ground cable. Proceed with the service by first removing the air cleaner outlet pipe followed by the four transaxle roll restrictor cross brace bolts which then allows removal of the cross brace. The service requires you to disconnect the evaporative emissions (EVAP) canister purge valve tube from the upper intake manifold while detaching the retainer and disconnecting the positive crankcase ventilation (PCV) along with its Brake Booster and vacuum harness tubes. The technician should detach the fuel tube retainer and disconnect the exhaust gas recirculation (EGR) system module electrical connector together with the vacuum tube which also requires removal from the upper intake manifold vacuum tube retainer. The procedure for early builds consists of plugging the Throttle Body along with both the PCV coolant hoses whereas late builds require plugging both PCV coolant hoses. First detach the throttle body electrical connector before removing and discarding any four upper-to-lower intake manifold screws installed when present. Next, install the eight bolts along the upper intake manifold after discarding the gaskets. After cleansing all sealing surfaces install the upper intake manifold and bolt it into place with eight bolts to be tightened to 10 Nm (89 inch lbs.) following the specified installation order. To reconnect the electrical throttle body install the throttle body connector while late builds require linking the two PCV coolant hoses although early builds need tubing connections between throttle body and PCV coolant. Install the EGR system module tube onto the EGR system module while applying 40 Nm (30 ft. lbs.) torque and join the vacuum tube to its upper intake manifold tube retainer. Connect the electrical connector of the EGR system module with a vacuum tube while you secure the fuel tube retainer and join the PCV and brake booster and vacuum harness tubes to the upper intake manifold. Fasten the EVAP canister purge valve tube before installing its retainer. Apply new thread-lock to the bolts after brushing them with a wire brush then install the transaxle roll restrictor cross brace before tightening these bolts to 55 Nm (41 ft. lbs.). New threadlock goes on the transaxle roll restrictor cross brace-to-roll restrictor bolt before installing a new bolt that should be torqued to 48 Nm (35 ft. lbs.). The last step includes reconnecting the battery ground cable then installing the air cleaner outlet pipe and finally performing the cooling system fill and bleed operations.
