OEM Lincoln Town Car Windshield

Lincoln Town Car Windshield Parts Questions & Experts Answers

• Windshield
  3W1Z-5403100-AA
  Q: How to service and repair a windshield on Lincoln Town Car?

  A: Start the windshield servicing or repair process by taking off the cowl panel grille followed by the interior rear view mirror along with the instrument panel defroster opening grille. First disconnect electrical connectors then remove part of the front door Weather Strips before extracting the LH and RH A-pillar trim panels along with their attached LH and RH sun visors and clip components. Proceed by lowering the front portion of the headliner and use either an oil-free compressed air stream or a clean shop towel to clear dirt away from the windshield pinch weld area. Before operating the Deluxe Windshield Removal Tool you need to apply water to the urethane adhesive. Anyone performing this procedure should always wear protective gloves together with eye protection to prevent injuries. The process of windshield removal requires you to avoid any contact with either paint or primer at this pinch weld area to prevent rust. Layer the blade inside the Deluxe Windshield Removal Tool with the flat plane in contact with the glass to initiate a urethane adhesive cut from the top center toward the bottom corners. Distabllish the windscreen glass from the body by operating The Pumper and cut remaining urethane adhesive before you can delicately remove the glass pane and position it on a firm work space. The new windshield glass should be positioned on the urethane adhesive bead according to existing lines before centering it within the opening and making changes to stop blocks if required. Linleshoot the windshield glass for position against the body before removing it to position flat on a stable surface with its interior facing upwards. It is essential to fix any pinch weld corrosion as this structure needs attention before the spray foam installation. Protect the pinch weld from scratches throughout the process. The pinch weld area needs thorough cleaning after which you should clean any old urethane adhesive from the site before applying new adhesive. Sitting should start from the top center V notch position in the ceramic paint while seating the windshield moulding evenly against the glass border. Apply glass primer on the windshield glass after cleaning it with glass cleaner following manufacturer directions and wait for the primer to dry for at minimum 6 minutes. Cut the urethane adhesive applicator tip according to specification before applying adhesive to the trimmed bead while avoiding gaps. Drive caution because the manufacturer requires you to wait until the urethane adhesive seal completes its curing according to the specified directions. Before placing the windshield glass open vehicle windows to reduce air pressure that affects adhesive bonding then position it according to previous marks. The urethane adhesive must cure for at least one hour until a full air and water leak test is conducted. Additional adhesive may be needed during testing. To complete the repair install the front headliner part and its sun visors with clips and LH and RH A-pillar trim panels together with front door weather strips and an instrument panel defroster opening grille while reconnecting electrical connectors and installing the interior rear view mirror before finishing by putting on the cowl panel grille.
