How to service the rear seat armrest on Mercury Milan?

The servicing of the rear seat armrest starts by taking out the rear seat cushion before removing the 60 percent rear seat backrest. You need to access the armrest-to-backrest bolts through the lower J-strip opening by partially turning the backrest trim cover and removing all four armrest-to-backrest bolts and the support plate. For fitting the armrest position it horizontally before securing the bolts to a torque point of 10 Nm (89 lb-in). Position the armrest assembly with bracket apart from the backrest portion before setting them aside while maintaining alignment of the armrest bracket tab with the frame during final reassembly. The armrest trim cover panel and its assembly can be removed by releasing the four pin-type retainers so you can get to the backrest. Replacing a damaged retainer requires pushing the remaining end through the backrest frame before installation of a new pin-type retainer. The repair process ends by first installing the armrest assembly then completing the installation of both the 60 percent rear seat backrest assembly as well as the rear seat cushion.

OEM Mercury Milan Armrest

Car Armrest

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

26 Armrests found

View related parts
Mercury Milan Armrest Assembly, Camel/Charcoal Black, Rear Part Number: 7E5Z-5467112-AB
Product Specifications
- Other Name: Seat Armrest, Rear; Arm Rest
- Position: Rear
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2008 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly, Camel, Rear Part Number: 7E5Z-5467112-BB
Product Specifications
- Other Name: Seat Armrest, Rear; Arm Rest
- Manufacturer Note: (YC)
- Position: Rear
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2008 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly, Camel, Rear Part Number: 9E5Z-5467112-AB
Product Specifications
- Other Name: Seat Armrest, Rear; Arm Rest
- Position: Rear
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2009 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly Part Number: 6E5Z-5467112-AG
Product Specifications
- Other Name: Arm Rest
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2006-2007 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly, Camel Part Number: 6E5Z-5467112-AH
Product Specifications
- Other Name: Arm Rest
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2006-2007 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly, Charcoal Black Part Number: 6E5Z-5467112-AJ
Product Specifications
- Other Name: Arm Rest
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2006-2007 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly, Camel Part Number: 6E5Z-5467112-BE
Product Specifications
- Other Name: Arm Rest
- Manufacturer Note: (YC)
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2006-2007 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly, Charcoal Black Part Number: 6E5Z-5467112-BF
Product Specifications
- Other Name: Arm Rest
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2006-2007 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly, Rear Part Number: 7E5Z-5467112-AA
Product Specifications
- Other Name: Seat Armrest, Rear; Arm Rest
- Position: Rear
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2008 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly, Charcoal Black Part Number: 7E5Z-5467112-AC
Product Specifications
- Other Name: Arm Rest
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2008 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly, Charcoal Black, Rear Part Number: 7E5Z-5467112-BC
Product Specifications
- Other Name: Seat Armrest, Rear; Arm Rest
- Position: Rear
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2008 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly, Rear Part Number: 9E5Z-5467112-AA
Product Specifications
- Other Name: Seat Armrest, Rear; Arm Rest
- Position: Rear
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2009 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly, Charcoal Black, Rear Part Number: 9E5Z-5467112-AC
Product Specifications
- Other Name: Seat Armrest, Rear; Arm Rest
- Position: Rear
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2009 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly, Camel, Rear Part Number: 9E5Z-5467112-BB
Product Specifications
- Other Name: Seat Armrest, Rear; Arm Rest
- Manufacturer Note: (YC)
- Position: Rear
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2009 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly Part Number: 9N7Z-5467112-AA
Product Specifications
- Other Name: Arm Rest
- Manufacturer Note: (RW)
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2009 Mercury Milan | Base, Premier | 4 Cyl 2.3 L GAS, 6 Cyl 3.0 L GAS
View related parts
Mercury Milan Armrest Assembly, Charcoal Black Part Number: BN7Z-5467112-AA
Product Specifications
- Other Name: Arm Rest
- Manufacturer Note: (BW)
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2011 Mercury Milan | Base, Premier | 4 Cyl 2.5 L GAS, 6 Cyl 3.0 L FLEX
View related parts
Mercury Milan Armrest Assembly, Rear Part Number: AE5Z-5467112-CA
Product Specifications
- Other Name: Seat Armrest, Rear; Arm Rest
- Manufacturer Note: (FL)
- Position: Rear
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2010-2011 Mercury Milan | Hybrid | 4 Cyl 2.5 L FULL HYBRID EV-GAS (FHEV)
View related parts
Mercury Milan Armrest Assembly, Rear Part Number: AE5Z-5467112-DA
Product Specifications
- Other Name: Seat Armrest, Rear; Arm Rest
- Manufacturer Note: (TL)
- Position: Rear
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2010-2011 Mercury Milan | Hybrid | 4 Cyl 2.5 L FULL HYBRID EV-GAS (FHEV)
View related parts
Mercury Milan Armrest Assembly, Camel, Rear Part Number: AE5Z-5467112-CB
Product Specifications
- Other Name: Seat Armrest, Rear; Arm Rest
- Position: Rear
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2010-2011 Mercury Milan | Base, Premier | 4 Cyl 2.5 L GAS, 6 Cyl 3.0 L FLEX
View related parts
Mercury Milan Armrest Assembly Part Number: AN7Z-5467112-AA
Product Specifications
- Other Name: Arm Rest
- Manufacturer Note: (EL)
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2010-2011 Mercury Milan | Base, Premier | 4 Cyl 2.5 L GAS, 6 Cyl 3.0 L FLEX

| Page 1 of 2 |Next >

1-20 of 26 Results

Mercury Milan Armrest

OEM Armrest boasts unmatched quality. Each part goes through full quality checks. They adhere to Mercury's official factory standards. These steps remove flaws and inconsistencies. So you can get Armrest with long life and a perfect fit. Come to our website and find genuine Mercury Milan parts. We keep a wide inventory of OEM Milan parts at the highly affordable prices. It's easy to search, compare, and pick what you need. You'll love the clear info and simple checkout. We offer top-rated customer service, and we reply fast. We also ship promptly to ensure your order arrives on time.

Mercury Milan Armrest Parts and Q&A

Armrest Assembly, Rear
7E5Z-5467112-AA
Q: How to service the rear seat armrest on Mercury Milan?
A:
The servicing of the rear seat armrest starts by taking out the rear Seat Cushion before removing the 60 percent rear seat backrest. You need to access the armrest-to-backrest bolts through the lower J-strip opening by partially turning the backrest trim cover and removing all four armrest-to-backrest bolts and the support plate. For fitting the armrest position it horizontally before securing the bolts to a torque point of 10 Nm (89 lb-in). Position the armrest assembly with bracket apart from the backrest portion before setting them aside while maintaining alignment of the armrest bracket tab with the frame during final reassembly. The armrest trim cover panel and its assembly can be removed by releasing the four pin-type retainers so you can get to the backrest. Replacing a damaged retainer requires pushing the remaining end through the backrest frame before installation of a new pin-type retainer. The repair process ends by first installing the armrest assembly then completing the installation of both the 60 percent rear seat backrest assembly as well as the rear seat cushion.
