How to service the rear drive axle shafts on Mercury Montego?

The service procedure for rear axle shafts starts by placing the vehicle in neutral position and hoisting it for access. Start by detaching the disc brake caliper through anchor bolt unscrewing while sustaining the components with mechanics wire to protect the brake hose. The installation process requires caliper torque to reach 110 Nm at 81 ft.lb. The rear axle wheel end nut requires replacement with a new one before tightening it to 200 Nm (148 ft. lbs.) through continuous rotation because this is a torque prevailing design nut that produces incorrect torque readings leading to bearing failure. Removal of the anti-lock sensor bolt should be followed by tightening the component to 14 Nm (10 ft. lbs.) before reinstalling. A suitable hub remover allows you to gently press the axle shaft until it becomes free from the hub, and then you can take out the brake disc screw and brake disc for reinstallation at 21 Nm (16 ft. lbs.) torque. The hub requires its four bolts to be removed together with the component before reinstallation where each bolt needs torque to 120 Nm (89 ft. lbs.). Using a prybar to gradually extract the axle shaft from the axle components will allow you to remove it. New circlips must be installed whenever you take out the axle shaft while beginning at one groove end and working the circlip across the axle shaft to stop its expansion. The reverse process should be used to finish the procedure.

OEM Mercury Montego Axle Shaft

Car Axle Shaft

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

6 Axle Shafts found

View related parts
Mercury Montego Axle Assembly, Front Passenger Side Part Number: 5F9Z-3B436-BA
$158.52 MSRP: $219.29
You Save: $60.77 (28%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Shaft - Front Axle; CV Axle Assembly, Front Right; GSP CV Axle; Axle Shaft; CV Axle Assembly
- Position: Front Passenger Side
- Replaces: 6F9Z-3B436-B
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2006-2007 Mercury Montego | Luxury, Premier | 6 Cyl 3.0 L GAS
View related parts
Mercury Montego Axle Shaft Assembly, Rear Passenger Side Part Number: 6F9Z-4K138-A
Product Specifications
- Other Name: Shaft Assembly; CV Axle Assembly, Rear Left, Rear Right; Axle Shaft; Axle Assembly
- Position: Rear Passenger Side
- Replaces: 5F9Z-4K138-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2005-2007 Mercury Montego | Luxury, Premier | 6 Cyl 3.0 L GAS
View related parts
Mercury Montego Axle Assembly, Front Driver Side Part Number: 5F9Z-3B437-AA
Product Specifications
- Other Name: Shaft - Front Axle; CV Axle Assembly, Front Left; GSP CV Axle; Axle Shaft; CV Axle Assembly
- Position: Front Driver Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2005-2007 Mercury Montego | Luxury, Premier | 6 Cyl 3.0 L GAS
View related parts
Mercury Montego Axle Assembly, Front Passenger Side Part Number: 5F9Z-3B436-CA
Product Specifications
- Other Name: Shaft - Front Axle; CV Axle Assembly, Front Right; GSP CV Axle; Axle Shaft; CV Axle Assembly
- Position: Front Passenger Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2005-2006 Mercury Montego | Luxury, Premier | 6 Cyl 3.0 L GAS
View related parts
Mercury Montego Axle Assembly, Front Passenger Side Part Number: 5F9Z-3B436-AA
Product Specifications
- Other Name: Shaft - Front Axle; CV Axle Assembly, Front Right; GSP CV Axle; Axle Shaft; CV Axle Assembly
- Position: Front Passenger Side
- Replaces: 6F9Z-3B436-A
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2005-2007 Mercury Montego | Luxury, Premier | 6 Cyl 3.0 L GAS
View related parts
Mercury Montego Axle Assembly, Front Driver Side Part Number: 5F9Z-3B437-BA
Product Specifications
- Other Name: Shaft - Front Axle; CV Axle Assembly, Front Left; GSP CV Axle; Axle Shaft; CV Axle Assembly
- Position: Front Driver Side
- Replaces: 6F9Z-3B437-A
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2005-2007 Mercury Montego | Luxury, Premier | 6 Cyl 3.0 L GAS

Mercury Montego Axle Shaft

OEM Axle Shaft boasts unmatched quality. Each part goes through full quality checks. They adhere to Mercury's official factory standards. These steps remove flaws and inconsistencies. So you can get Axle Shaft with long life and a perfect fit. Come to our website and find genuine Mercury Montego parts. We keep a wide inventory of OEM Montego parts at the highly affordable prices. It's easy to search, compare, and pick what you need. You'll love the clear info and simple checkout. We offer top-rated customer service, and we reply fast. We also ship promptly to ensure your order arrives on time.

Axle Shaft is one of the strong pillars of the Mercury Montego series as it contributes to the better working and safety of the vehicle. This important assembly enables the power to be passed from the differential to the wheels, providing the letting them to spin in an individual manner which in turn increases the tractive forces available during turning. All the Mercury Montego models from 1968 to 2007 contain the details of various types of axles used and halfshaft, depending on the version of suspension system. Solid axles offer strength and bearing capacity to the design and halfshafts to provide better ride quality due to independent operation of wheels. The Axle Shaft can fit into different generations of Montego hence the drivers reap the benefits of a better handling and stability car. Interestingly the third generation Mercury Montego was the first of its kind to feature a front wheel drive perhaps explaining why the Axle Shaft was considered fundamental to a smooth drive. Some of these are the incorporate of enhanced safety features than its competitors and it can perform in various terrains. Due to the trustworthiness of Axle Shaft in terms of durability and performance, the efficiency of the car when operating and boosting the safety of passengers is guaranteed, making the Mercury Montego an efficient car to buy.

Mercury Montego Axle Shaft Parts and Q&A

Axle Shaft Assembly, Rear Passenger Side
6F9Z-4K138-A
Q: How to service the rear drive axle shafts on Mercury Montego?
A:
The service procedure for rear axle shafts starts by placing the vehicle in neutral position and hoisting it for access. Start by detaching the disc Brake Caliper through anchor bolt unscrewing while sustaining the components with mechanics wire to protect the brake hose. The installation process requires caliper torque to reach 110 Nm at 81 ft.lb. The rear axle wheel end nut requires replacement with a new one before tightening it to 200 Nm (148 ft. lbs.) through continuous rotation because this is a torque prevailing design nut that produces incorrect torque readings leading to bearing failure. Removal of the anti-lock sensor bolt should be followed by tightening the component to 14 Nm (10 ft. lbs.) before reinstalling. A suitable hub remover allows you to gently press the axle shaft until it becomes free from the hub, and then you can take out the Brake Disc screw and brake disc for reinstallation at 21 Nm (16 ft. lbs.) torque. The hub requires its four bolts to be removed together with the component before reinstallation where each bolt needs torque to 120 Nm (89 ft. lbs.). Using a prybar to gradually extract the axle shaft from the axle components will allow you to remove it. New circlips must be installed whenever you take out the axle shaft while beginning at one groove end and working the circlip across the axle shaft to stop its expansion. The reverse process should be used to finish the procedure.
