Diagram (1 of 1): Transmission Components (Automatic Transmission)
Sort by:
Ref No.
Ref No.
Part No. & Part Description
Price & Qty.
Part No. &
Part Description
Part Description
- 1
$166.67 $114.501 - 1
$123.67 $84.961
- 2
$20.11 $14.186 - 2
$3.04 $1.7910
- 3
- 4
$61.17 $42.761
- 5
$33.50 $23.621
- 6
$49.64 $32.081
$36.73 $23.741
-N811360-S309
Bolt- Part Notes: (AB-175-NK) Bolt M10X1.5X60 hex flanged head - attaches 7005 to engine, 6.0L
- Require Quantity: 2
- Package Quantity: 4
- Callout Name: 7005
- Replaced By: -N811360-S439
$17.15 $10.08
$22.60 $13.28
$72.33 $50.56
$4.25 $2.50
$13.00 $7.64
3C3Z-7B066-CB
Plate - Clutch Pressure- Part Notes: 3C3P-E*,G*;4C3P-J*,K*;5C3P-CB,DB,JB,KB
- Callout Name: 7B066
$82.17 $56.45
4C3Z-7E440-AA
Switch - Pressure- Part Notes: FROM 02/01/04
- Require Quantity: 5
- Package Quantity: 1
- Callout Name: 7E440
$45.45 $29.38
E9TZ-7B066-B
Plate - Clutch Pressure- Part Notes: 12.34-12.60mm thick, YC3P-A*,B*;1C3P-A*,B*
- Callout Name: 7B066
-N606067-S2
Bolt- Part Notes: Bolt (case to engine) M10 - 1.50 x 75 (metric) , Speed: 6, Type: ZFHD
- Fit Note: 10 Cyl 6.8L, 8 Cyl 5.4L
- Require Quantity: 2
- Package Quantity: 4
- Callout Name: 7005
- Replaced By: -N606067-S439
$29.40 $17.27
F81Z-7034-BA
Valve Assy - Vent- Part Notes: Vent - hose nipple style, YC3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*;1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*
- Callout Name: 7034
- Replaced By: 1C3Z-7034-AA
$47.00 $33.14
$33.67 $23.74
E9TZ-7B066-C
Plate - Clutch Pressure- Part Notes: Plate - steel - Intermediate clutch - 3.13-3.23mm thick - 157.2-157.8mm I.D. - 26 teeth in a 30 tooth profile - 1 used as a pressure plate, 2 used as steel plates (7B442).
- Require Quantity: 3
- Package Quantity: 1
- Callout Name: 7B066
E9TZ-7B442-D
Driven Plate - Steel- Part Notes: Direct clutch
Forward Clutch - Require Quantity: 4
- Package Quantity: 4
- Callout Name: 7B442
$13.50 $9.52- Part Notes: Direct clutch
F81Z-7B442-AA
Driven Plate - Steel- Part Notes: Coast clutch, 1C3P-A*,B*,C*,D*,E*,F*
Coast clutch, 1C3P-H*,J*,L*,M* - Require Quantity: 3
- Package Quantity: 1
- Callout Name: 7B442
-372552-S2
Nut - Spring- Part Notes: Nut, spring - 3/8" - attaches id tag to case
Nut, spring - 3/8" - attaches id tag to case, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M* - Callout Name: 7005
$2.13 $1.25
- C6AZ-7B066-B
Plate - Clutch Pressure- Part Notes: 11/32" thick - 5 1/8" I.D. - 26 teeth, YC3P-A*,B*,C*,D*,H*,J*;1C3P-A*,B*,C*,D*,H*,J*
Rear - 11/32" thick - 5 1/8" I.D. - 26 teeth, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M* - Location: Rear
- Callout Name: 7B066
$69.50 $48.58
- $22.60 $13.28
$0.85 $0.51
-W707410-S427
Bolt- Part Notes: Bolt (case to engine) M10 - 1.50 x 65 (metric) , Speed: 6, Type: ZFHD
- Fit Note: 10 Cyl 6.8L, 8 Cyl 5.4L
- Require Quantity: 5
- Package Quantity: 4
- Callout Name: 7005
- Replaced By: -W707410-S439
$4.25 $2.50
$10.00 $5.88
E9TZ-7B442-E
Driven Plate - Steel- Part Notes: Reverse clutch , YC3P,A*,B*,C*,D*,H*,J*;1C3P,A*,B*,C*,D*,H*,J*
Reverse clutch , YC3P,E*,F*,L*,M*;;1C3P,E*,F*,L*,M* - Require Quantity: 5
- Package Quantity: 6
- Callout Name: 7B442
$13.00 $9.17
$3.25 $1.92
F81Z-7017-EA
Shaft - Input- Part Notes: 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*
- Callout Name: 7017
- Replaced By: 6C3Z-7017-A
$94.33 $64.81
F5TZ-7025-A
Bushing- Part Notes: Rear - bushing - with one lubrication groove, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*
- Location: Rear
- Callout Name: 7025
$20.50 $14.45
2C3Z-7A031-AA
Tube- Part Notes: Outlet tube, Z/F, S6-650
- Fit Note: 10 Cyl 6.8L, 8 Cyl 5.4L
- Callout Name: 7A030
F3AZ-7034-AA
Vent Assy- Part Notes: 3C3P-E*,G*;4C3P-J*,K*;5C3P-AB,BB,CB,DB,JB,KB
- Callout Name: 7034
- Replaced By: 6L3Z-7034-A
$14.05 $9.91
- F2TZ-7025-A
Bushing- Part Notes: Front - bushing, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*
- Location: Front
- Callout Name: 7025
$43.33 $30.55
-370443-S32
Clip- Part Notes: Clip - vent hose
- Require Quantity: 2
- Package Quantity: 4
- Callout Name: 7034
- Replaced By: -W715465-S439
$4.25 $2.50
C6AZ-7B066-A
Plate - Clutch Pressure- Part Notes: Front - 19/64" thick - 5 1/8" I.d. - 26 teeth, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*
- Location: Front
- Callout Name: 7B066
$29.50 $20.80
- F7TZ-7B066-AA
Plate - Clutch Pressure- Part Notes: .710" thick, YC3P-A*,B*,C*,D*,H*,J*;1C3P-A*,B*,C*,D*,H*,J*
- Callout Name: 7B066
- -W704802-S427
Bolt- Part Notes: Bolt M10X95.75 hex flanged piloted - attaches 7005 to engine, 6.0L
- Require Quantity: 7
- Package Quantity: 4
- Callout Name: 7005
- Replaced By: -W704802-S439
$15.50 $9.11
-390685-S
Plug - Threaded- Part Notes: (090-010) Plug - pressure tap - 1/8"-27 x .65"
(090-010) Plug - pressure tap - 1/8"-27 x .65", 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M* - Callout Name: 7005
$10.00 $5.88
