2004 Ford F-350 Super Duty Automatic Transmission, Transmission

Part Notes: Radiator fitting; For seal, refer to E5LY 8C242-A (only works with OE radiator, replacement radiator fitting is PIA to radiator)

Part Notes: 11/32" thick - 5 1/8" I.D. - 26 teeth, YC3P-A*,B*,C*,D*,H*,J*;1C3P-A*,B*,C*,D*,H*,J*
Rear - 11/32" thick - 5 1/8" I.D. - 26 teeth, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*

Part Notes: 12.34-12.60mm thick, YC3P-A*,B*;1C3P-A*,B*

Part Notes: Plate , friction , 1C3P,A*,B*,C*,D*,E*,F*
Plate , friction , 1C3P,H*,J*,L*,M*

Part Notes: Bolt M10X95.75 hex flanged piloted - attaches 7005 to engine, 6.0L

Part Notes: Bolt (case to engine) M10 - 1.50 x 65 (metric) , Speed: 6, Type: ZFHD

Part Notes: #17 thrust, 3C3P-E*,H*;4C3P-JB;5C3P-AB,CB,EB,JB,LB

Part Notes: #17 thrust, 3C3P-G*,J*;4C3P-KB;5C3P-BB,DB,FB,KB,MB

Part Notes: Brown - rubber ball- 5/16" - 8 used in 7005, 2 in 7A100, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*

Part Notes: Plug - used to plug OSS/TSS hole when sensor is not used., 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*

Part Notes: (090-010) Plug - pressure tap - 1/8"-27 x .65"
(090-010) Plug - pressure tap - 1/8"-27 x .65", 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*

Part Notes: Plate - friction, 1C3P-AC,BC,CC,DC,EB,FB,HC,JC,LB,MB

Part Notes: Christmas tree with 6 inch adjustable plastic tie

Part Notes: Vent - hose nipple style, YC3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*;1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*

Part Notes: (QQ-98B) Ring, retaining - 7" O.D. - .094" thick-(7B066 to 7A360), 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*
(QQ-98B) Ring, retaining - 7" O.D. - .094" thick-(7B066 to 7F283)

Part Notes: 3/8 x 18 mm pipe-LH side of Cyl. Block/front of head

Part Notes: Front - 19/64" thick - 5 1/8" I.d. - 26 teeth, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*

Part Notes: Plate - steel - Intermediate clutch - 3.13-3.23mm thick - 157.2-157.8mm I.D. - 26 teeth in a 30 tooth profile - 1 used as a pressure plate, 2 used as steel plates (7B442).

Part Notes: Coast clutch, 1C3P-A*,B*,C*,D*,E*,F*
Coast clutch, 1C3P-H*,J*,L*,M*

Part Notes: Outer-flair lip seal - 8 13/32" O.D. x 7 29/32" I.D., 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*

Part Notes: OSS/TSS from flat of surface on magnetized end is 37 mm long, YC3P-A*,B*,C*,D*,E*,F*;1C3P-A*,B*,C*,D*,E*,F*
OSS/TSS from flat of surface on magnetized end is 37 mm long, YC3P-H*,J*,L*,M*;1C3P-H*,J*,L*,M*

Part Notes: Ball - EPC blow off - .25" - steel, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*

Part Notes: (QQ-96)Ring, retaining - 7" O.D. - .076" thick-(7B066 to 7A360), 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*
(QQ-96)Ring,retaining - 7" O.D. - .076" thick-(7B066 to 7F283)

Part Notes: Plate - friction, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*

Part Notes: Reverse clutch , YC3P,A*,B*,C*,D*,H*,J*;1C3P,A*,B*,C*,D*,H*,J*
Reverse clutch , YC3P,E*,F*,L*,M*;;1C3P,E*,F*,L*,M*

Part Notes: Retainer - push pin type - 20mm serrated pin with 60mm x 10mm wing - general use for wiring to sheet metal or blind hole retention. Use electrical tape to secure to harness. 10 per package., Service Repair Only

Part Notes: (AB-175-NK) Bolt M10X1.5X60 hex flanged head - attaches 7005 to engine, 6.0L

Part Notes: TSS From flat of surface on magnetized end is 18.91mm long, 2 pin connector, YC3P-H*,J*,L*,M*;1C3P-H*,J*,L*,M*

Part Notes: Inner (small) 3.00" O.D. 'O' ring type seal, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*

Part Notes: .710" thick, YC3P-A*,B*,C*,D*,H*,J*;1C3P-A*,B*,C*,D*,H*,J*

Part Notes: 3C3P-E*,G*;4C3P-J*,K*;5C3P-AB,BB,CB,DB,JB,KB

Part Notes: Nut, spring - 3/8" - attaches id tag to case
Nut, spring - 3/8" - attaches id tag to case, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*

Part Notes: Bolt (case to engine) M10 - 1.50 x 75 (metric) , Speed: 6, Type: ZFHD

Part Notes: Note: Kit does not include 7D100 and 7C155 gaskets - must order gaskets separately

Part Notes: Located in rear axle housing, used as ABS sensor

Part Notes: 7A360 (forward cylinder) to 7A130 (center support)

Part Notes: Green - rubber ball - 1/4" - used in 7A100, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*

Part Notes: Plug - lubrication - rear of case
Plug - lubrication - rear of case, 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*

Part Notes: (QQ-98H) Ring, retaing - 7" O.D. - .058" thick-(7B066 to 7D044), 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*
(QQ-98H) Ring, retaining - 7" O.D. - .058" thick-(7B066 to 7A360), 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*
(QQ-98H) Ring, retaining - 7" O.D. - .058" thick-(7B066 to 7F283)

Part Notes: (QQ-97)Ring, retaining - 7" O.D. - .085" thick-(7B066 to 7D044), 1C3P-A*,B*,C*,D*,E*,F*,H*,J*,L*,M*
(QQ-97)Ring, retaining - 7" O.D. - .085" thick-(7B066 to 7F283)
