OEM Ford E-150 Leaf Spring

Leaf Helper Spring
  • Select Vehicle by Model
  • Select Vehicle by VIN
Select Vehicle by Model
Make
Model
Year
or
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

4 Leaf Springs found

  • Ford E-150 Leaf Spring - 8C2Z-5560-RB
    Ford E-150 Leaf Spring Diagram - 8C2Z-5560-RB
    View related parts

    Ford E-150 Leaf Spring, Rear
    Part Number: 8C2Z-5560-RB

    $315.87 MSRP: $463.83
    You Save: $147.96 (32%)
    Ships in 1-3 Business Days
    ADD TO CART
    Product Specifications
    • Other Name: Spring - Rear; Leaf Spring, Rear
    • Position: Rear
    • Replaces: 5C2Z-5560-RA, F5UZ-5560-C
    • Warranty: This genuine part is guaranteed by Ford's factory warranty.
    Fits the following Vehicles:
    • 2003-2014 Ford E-150 | Base, Chateau, XL, XLT | 6 Cyl 4.2 L GAS, 8 Cyl 4.6 L FLEX, 8 Cyl 4.6 L GAS, 8 Cyl 5.4 L CNG, 8 Cyl 5.4 L FLEX, 8 Cyl 5.4 L GAS, 8 Cyl 5.4 L LPG
  • Ford E-150 Leaf Spring - 8C2Z-5560-AB
    Ford E-150 Leaf Spring Diagram - 8C2Z-5560-AB
    View related parts

    Ford E-150 Leaf Spring, Rear
    Part Number: 8C2Z-5560-AB

    $287.83 MSRP: $448.33
    You Save: $160.50 (36%)
    Ships in 1-2 Business Days
    ADD TO CART
    Product Specifications
    • Other Name: Spring - Rear; Leaf Spring, Rear
    • Position: Rear
    • Warranty: This genuine part is guaranteed by Ford's factory warranty.
    Fits the following Vehicles:
    • 2008-2014 Ford E-150 | Base, XL, XLT | 8 Cyl 4.6 L FLEX, 8 Cyl 4.6 L GAS, 8 Cyl 5.4 L CNG, 8 Cyl 5.4 L FLEX, 8 Cyl 5.4 L GAS, 8 Cyl 5.4 L LPG
  • Ford E-150 Leaf Spring - 5C2Z-5560-VA
    Ford E-150 Leaf Spring Diagram - 5C2Z-5560-VA
    View related parts

    Ford E-150 Leaf Spring, Rear
    Part Number: 5C2Z-5560-VA

    Product Specifications
    • Other Name: Spring - Rear
    • Manufacturer Note: Spring code 6
    • Position: Rear
    • Replaces: 4C2Z-5560-VA
    • Warranty: This genuine part is guaranteed by Ford's factory warranty.
    Fits the following Vehicles:
    • 2005-2007 Ford E-150 | Base, Chateau, XL, XLT | 8 Cyl 4.6 L GAS, 8 Cyl 5.4 L GAS
  • Ford E-150 Leaf Spring - 7C2Z-5560-A
    Ford E-150 Leaf Spring Diagram - 7C2Z-5560-A
    View related parts

    Ford E-150 Leaf Spring, Rear
    Part Number: 7C2Z-5560-A

    Product Specifications
    • Other Name: Spring - Rear
    • Position: Rear
    • Warranty: This genuine part is guaranteed by Ford's factory warranty.
    Fits the following Vehicles:
    • 2008 Ford E-150 | Base, XL, XLT | 8 Cyl 4.6 L GAS, 8 Cyl 5.4 L GAS

Ford E-150 Leaf Spring

Welcome to our website where you can discover high-quality, genuine Ford E-150 Leaf Spring. We offer an extensive inventory of OEM Ford E-150 Leaf Spring at affordable prices. We are committed to providing top-rated customer service along with prompt delivery.

Ford E-150 Leaf Spring Parts Questions & Experts Answers

  • Ford E-150 Leaf Spring - 8C2Z-5560-RB Leaf Spring, Rear Leaf Spring, Rear
    8C2Z-5560-RB
    Q: How to service and repair the leaf spring on Ford E-150?
    A: Start leaf spring service and repair operations on a hoisted vehicle set in NEUTRAL gear. Steady the rear axle region by using a proper jack during the process. First take off the Shock Absorber lower nut and bolt before throwing out the nut and then secure the nut to 70 Nm (52 ft. lbs.). Begin by taking away the four U-bolt nuts alongside the plate and two U-bolts and disposing of the parts. The installer needs to tighten U-bolts to 115 Nm (85 ft. lbs.) for the E-150 models and 175 Nm (129 ft. lbs.) for E-250, E-350 and E-450 chassis. Use a suitable wrench to remove the leaf spring front bracket bolt and flagnut before installation where the torque should be set to 200 Nm (148 ft. lbs.) for E-150 but to 350 Nm (258 ft. lbs.) for E-250, E-350, and E-450. The next step involves removing the leaf spring shackle-to-bracket bolt together with its flagnut before discarding them while installation should be done at 133 Nm (98 ft. lbs.). To install the leaf springs you should dispose of the nut and bolt then fasten all parts to 133 Nm (98 ft. lbs.). The complete procedure ends by performing the installation steps in reverse order.

Related Ford E-150 Parts

Browse Ford E-150 Leaf Spring by Years

+
2014 2013 2012 2011 2010 2009 2008 2007 2006 2005 2004 2003
