How to Ensure Proper Functioning of the Thermostat on a 3.0L (2V) Engine in a Ford Ranger?

The service procedure for the thermostat on a 3.0L (2V) engine starts with draining the cooling system. You should first remove the bolt keeping the throttle body cover in place together with the air cleaner outlet tube. Detach the upper radiator hose from the thermostat outlet housing then take out the alternator wiring pin-type retainer. Remove all bolts and then take away the thermostat outlet housing and thermostat from the engine block. The installation requires nuts to achieve Torque of 25 Nm (18 lb-ft). The process of scraping the thermostat housing-to-gasket interface demands careful attention to prevent damaging aluminum surfaces that could form leaks. You should remove the old gasket while cleaning both mating surfaces until they remain free from all remnants of gasket material. The completion of installation requires you to follow the reverse order of removal steps.

How to service the thermostat on Ford Ranger?

Service of the thermostat requires an initial draining of the cooling system. After disconnecting the heater return hose at the thermostat housing the technician must remove the engine coolant temperature sensor and the water temperature sensor. The next step requires removal of the upper radiator hose from its outlet connection. The water thermostat can be removed after extracting the elbow away from the cylinder head by removing bolts from its position. It is normal for the thermostat tabs to not fit perfectly with the housing because they will naturally secure themselves against the head during installation. Follow these steps to install the thermostat into the water outlet connection by applying manual pressure on the housing while fitting the tabs inside the housing recesses. Insert the water outlet housing onto the head with the thermostat while holding the thermostat in position. Reposition the constant tension clamp according to its original position and attach the upper radiator hose to the water outlet connection. After reconnecting the engine coolant temperature sensor and the water temperature sensor you must reinstall the constant tension clamp into its original position before connecting the heater return hose. Finally, fill the cooling system.

OEM Ford Ranger Thermostat

Engine Coolant Thermostat

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

10 Thermostats found

View related parts
Ford Ranger Thermostat Part Number: YF1Z-8575-BA
$9.69 MSRP: $15.38
You Save: $5.69 (37%)
ADD TO CART
Product Specifications
- Other Name: Thermostat Assembly; Engine Coolant Thermostat
- Replaces: F58Z-8575-A, F5DZ-8575-A
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1992-1995 Ford Ranger | Custom, S, Splash, Sport, STX, XL, XL Sport, XLT | 6 Cyl 3.0 L GAS
View related parts
Ford Ranger Thermostat Unit Part Number: 4L5Z-8575-B
$32.75 MSRP: $52.00
You Save: $19.25 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Thermostat Assembly; Engine Coolant Thermostat; Thermostat Integral; Thermostat
- Replaces: 4L5Z-8575-A, 4L5Z-8575-AA, 4L5Z-8575-AD
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2004-2006 Ford Ranger | XL, XLT | 4 Cyl 2.3 L GAS
View related parts
Ford Ranger Thermostat Housing Part Number: 3M4Z-8575-B
$30.23 MSRP: $48.00
You Save: $17.77 (38%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Thermostat Assembly; Engine Coolant Thermostat Kit; Thermostat Housing Cover; Thermostat Integral; Thermostat, Coolant; Thermostat Unit; Thermostat; Engine Coolant Thermostat
- Replaces: 3M4Z-8575-A, 3M4Z-8575-AB
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2007-2011 Ford Ranger | Sport, STX, XL, XLT | 4 Cyl 2.3 L GAS
View related parts
Ford Ranger Thermostat Part Number: 2L2Z-8575-AA
$21.07 MSRP: $33.45
You Save: $12.38 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Thermostat Assembly; Engine Coolant Thermostat
- Replaces: 1L2Z-8575-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2001-2011 Ford Ranger | Edge, FX4, Sport, STX, Tremor, XL, XLT | 6 Cyl 4.0 L GAS
View related parts
Ford Ranger Thermostat Housing Part Number: 1S7Z-8575-AG
$132.84 MSRP: $223.64
You Save: $90.80 (41%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Thermostat Assembly; Engine Coolant Thermostat; Thermostat Housing Cover; Thermostat
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2001-2003 Ford Ranger | XL, XLT | 4 Cyl 2.3 L GAS
View related parts
Ford Ranger Thermostat Part Number: YU3Z-8575-BA
$34.24 MSRP: $54.36
You Save: $20.12 (38%)
ADD TO CART
Product Specifications
- Other Name: Thermostat Assembly; Engine Coolant Thermostat; Thermostat, Coolant
- Replaces: F2TZ-8575-A
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1992-2003 Ford Ranger | Custom, Edge, S, Splash, Sport, STX, XL, XL Sport, XLT | 6 Cyl 2.9 L GAS, 6 Cyl 4.0 L GAS
View related parts
Ford Ranger Thermostat Part Number: LB5Z-8575-C
$29.96 MSRP: $46.36
You Save: $16.40 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Thermostat Assembly; Engine Coolant Thermostat
- Replaces: LB5Z-8575-B
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2019-2023 Ford Ranger | Lariat, XL, XLT | 4 Cyl 2.3 L GAS
View related parts
Ford Ranger Thermostat Part Number: KU2Z-8575-B
Product Specifications
- Other Name: Thermostat Assembly; Engine Coolant Thermostat
- Replaces: F6DZ-8575-AA, F6ZZ-8575-A, F8DZ-8575-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1998-2008 Ford Ranger | Edge, Splash, Sport, STX, Tremor, XL, XLT | 6 Cyl 3.0 L FLEX, 6 Cyl 3.0 L GAS
View related parts
Ford Ranger Thermostat Part Number: KU2Z-8575-A
Product Specifications
- Other Name: Thermostat Assembly; Engine Coolant Thermostat
- Replaces: F8CZ-8575-AA, F6TZ-8575-AC, YS4Z-8575-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1992-2001 Ford Ranger | Custom, S, Splash, Sport, STX, XL, XL Sport, XLT | 4 Cyl 2.3 L GAS, 4 Cyl 2.5 L GAS
View related parts
Ford Ranger Valve Cover Gasket Part Number: E6DZ8575B
Product Specifications
- Other Name: Thermostat; Engine Coolant Thermostat; Exhaust Valve Seals; Intake Valve Seals
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1991 Ford Ranger | Custom, S, Sport, STX, XLT | 6 Cyl 3.0 L GAS

Ford Ranger Thermostat

OEM Thermostat boasts unmatched quality. Each part goes through full quality checks. They adhere to Ford's official factory standards. These steps remove flaws and inconsistencies. So you can get Thermostat with long life and a perfect fit. Come to our website and find genuine Ford Ranger parts. We keep a wide inventory of OEM Ranger parts at the highly affordable prices. It's easy to search, compare, and pick what you need. You'll love the clear info and simple checkout. We offer top-rated customer service, and we reply fast. We also ship promptly to ensure your order arrives on time.

The Ford Ranger Thermostat mainly works in the car's cooling system and the part usually placed close to the car's radiator. These are mainly service to cool the engine while it is working to bring the temperatures within the engine to the most desirable levels. Thermostats are feedback control elements that consolidate the evaluation of temperature and actuation of the desired fixed temperature in household and industrial uses. Hence, other types of thermostats have included mechanical and pneumatic types that have been used over the years some of which include the wax pellet thermostat, and the pneumatic digital interface that helps in improving the efficiency and comfort in controlling temperature for the Ford ranger cars.

Ford Ranger Thermostat Parts and Q&A

Thermostat
2L2Z-8575-AA
Q: How to Ensure Proper Functioning of the Thermostat on a 3.0L (2V) Engine in a Ford Ranger?
A:
The service procedure for the thermostat on a 3.0L (2V) engine starts with draining the cooling system. You should first remove the bolt keeping the throttle body cover in place together with the air cleaner outlet tube. Detach the upper radiator hose from the thermostat outlet housing then take out the alternator wiring pin-type retainer. Remove all bolts and then take away the thermostat outlet housing and thermostat from the engine block. The installation requires nuts to achieve Torque of 25 Nm (18 lb-ft). The process of scraping the Thermostat Housing-to-gasket interface demands careful attention to prevent damaging aluminum surfaces that could form leaks. You should remove the old gasket while cleaning both mating surfaces until they remain free from all remnants of gasket material. The completion of installation requires you to follow the reverse order of removal steps.
Thermostat
YU3Z-8575-BA
Q: How to service the thermostat on Ford Ranger?
A:
Service of the thermostat requires an initial draining of the cooling system. After disconnecting the heater return hose at the Thermostat Housing the technician must remove the engine Coolant Temperature Sensor and the water temperature sensor. The next step requires removal of the upper radiator hose from its outlet connection. The water thermostat can be removed after extracting the elbow away from the cylinder head by removing bolts from its position. It is normal for the thermostat tabs to not fit perfectly with the housing because they will naturally secure themselves against the head during installation. Follow these steps to install the thermostat into the water outlet connection by applying manual pressure on the housing while fitting the tabs inside the housing recesses. Insert the water outlet housing onto the head with the thermostat while holding the thermostat in position. Reposition the constant tension clamp according to its original position and attach the upper radiator hose to the water outlet connection. After reconnecting the engine coolant temperature sensor and the water temperature sensor you must reinstall the constant tension clamp into its original position before connecting the heater return hose. Finally, fill the cooling system.
