How to service and repair the vacuum brake booster on Mercury Sable?

A correct start for vacuum brake booster servicing requires disconnecting the vehicle battery. Service and repairs of the vacuum brake booster start by disconnecting the Mass Air Flow (MAF) sensor along with breather tubes while also removing the outlet tube from the throttle body. Put the engine air cleaner housing cover to the side after removal. Service to the vacuum brake booster begins with stripping off the wiper mounting arm and pivot shaft then the brake master cylinder. The operational unit of the speed control module should be positioned aside by removing the electrical connector and unfastening the nuts. Remove the manual control lever cable from its connection to the Transmission Range Sensor (TRS) followed by the removal of the manual cable bracket nut and its bolts before placing the bracket aside. Next disconnect the check valve after removing both the vacuum outlet manifold assembly from its position. After discarding the nut detach the heater hose retainer and guide the hose away from the work area without separating the electrical connector. The first step requires removing two bolts which will allow you to take off the steering column opening cover. To disconnect the push rod start by removing its electrical connector along with the push rod retainer before sliding the push rod off the pin then continue by disconnecting the stoplight switch and washer and bushing. You need to remove the brake booster after discarding all nuts. You must follow these steps to install the new brake booster but do the Brake Booster Flush Rod Adjustment while using fresh nuts for assembly.

OEM Mercury Sable Brake Booster

Brake Power Booster

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

4 Brake Boosters found

View related parts
Mercury Sable Brake Booster Part Number: 8G1Z-2005-A
$310.38 MSRP: $429.39
You Save: $119.01 (28%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Booster Assembly - Brake; Power Brake Booster; Power Booster
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2008-2009 Mercury Sable | Base, Premier | 6 Cyl 3.5 L GAS
View related parts
Mercury Sable Brake Booster Part Number: 5F1Z-2005-A
$227.03 MSRP: $314.08
You Save: $87.05 (28%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Booster Assembly - Brake; Power Brake Booster; Power Booster
- Manufacturer Note: Sedan, from 2-22-2005
- Replaces: 3F1Z-2005-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2000-2005 Mercury Sable | GS, LS, LS Premium, Platinum Edition | 6 Cyl 3.0 L FLEX, 6 Cyl 3.0 L GAS
View related parts
Mercury Sable Brake Booster Part Number: 5F1Z-2005-B
Product Specifications
- Other Name: Booster Assembly - Brake; Power Brake Booster; Power Booster
- Replaces: 3F1Z-2005-BA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2001-2005 Mercury Sable | GS, LS, LS Premium | 6 Cyl 3.0 L FLEX, 6 Cyl 3.0 L GAS
View related parts
Mercury Sable Brake Booster Part Number: XF1Z-2005-AA
Product Specifications
- Other Name: Booster Assembly - Brake; Power Booster
- Manufacturer Note: exc. Flex Fuel
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1996-1999 Mercury Sable | G, GS, LS, LS Premium | 6 Cyl 3.0 L GAS

Mercury Sable Brake Booster

OEM Brake Booster boasts unmatched quality. Each part goes through full quality checks. They adhere to Mercury's official factory standards. These steps remove flaws and inconsistencies. So you can get Brake Booster with long life and a perfect fit. Come to our website and find genuine Mercury Sable parts. We keep a wide inventory of OEM Sable parts at the highly affordable prices. It's easy to search, compare, and pick what you need. You'll love the clear info and simple checkout. We offer top-rated customer service, and we reply fast. We also ship promptly to ensure your order arrives on time.

The Mercury Sable brake booster is one of the more important parts of the car since it plays a big role in boosting the braking system of the car, thus, making it an important feature in the series of Mercury Sable. Offering durability and function, the newly designed Brake Booster delivers the power to reduce the load on the driver in order to provide improved and safer driving. Most Mercury Sable models employ vacuum boosters which actuates from the pressure of the engine vacuum in relation to that of the atmosphere but includes hydraulic options as well. This makes the Brake Booster versatile enabling of larger diameter boosters to provide greater assistance while those with dual diaphragm can fit into tight spaces. Mercury Sable is a vehicle made by Mercury division of Ford which has gone through several generations and each subsequent generation of the car was receiving changes for the better starting with boosting its performance up to enhancing safety. The Brake Booster is evident in this evolution to ensure that the Sable remains relevant and efficient to the drivers in aspect of safety. Being an upgrade compatible with most of the Sable models, the Brake Booster also supplements the vehicle's characteristic by improving braking facility. Additional characteristics including its unique design and versatility puts Brake Booster in the market strategically as one of the best braking system when it comes to reliability and effectiveness. Lastly, the Brake Booster is another fine demonstration of the company's dedication to quality and performance and as such any Mercury Sable should come equipped with one.

Mercury Sable Brake Booster Parts and Q&A

Brake Booster
5F1Z-2005-A
Q: How to service and repair the vacuum brake booster on Mercury Sable?
A:
A correct start for vacuum brake booster servicing requires disconnecting the vehicle battery. Service and repairs of the vacuum brake booster start by disconnecting the Mass Air Flow (MAF) sensor along with breather tubes while also removing the outlet tube from the Throttle Body. Put the engine air cleaner housing cover to the side after removal. Service to the vacuum brake booster begins with stripping off the wiper mounting arm and pivot shaft then the Brake Master Cylinder. The operational unit of the speed control module should be positioned aside by removing the electrical connector and unfastening the nuts. Remove the manual control lever cable from its connection to the Transmission Range Sensor (TRS) followed by the removal of the manual cable bracket nut and its bolts before placing the bracket aside. Next disconnect the check valve after removing both the vacuum outlet manifold assembly from its position. After discarding the nut detach the heater hose retainer and guide the hose away from the work area without separating the electrical connector. The first step requires removing two bolts which will allow you to take off the steering column opening cover. To disconnect the push rod start by removing its electrical connector along with the push rod retainer before sliding the push rod off the pin then continue by disconnecting the stoplight switch and washer and bushing. You need to remove the brake booster after discarding all nuts. You must follow these steps to install the new brake booster but do the Brake Booster Flush Rod Adjustment while using fresh nuts for assembly.
