How to service the LH temperature blend door actuator on Lincoln MKX?

You start service of the LH temperature blend door actuator by taking out the two lower bolts from the steering column opening cover and detaching the cover. Take the in-vehicle temperature sensor aspirator hose and electrical connector off before moving the instrument panel wire harness aside from the actuator. Before lifting the actuator remove three screws holding the LH temperature blend door actuator plus disconnect its power link. Evaluate the LH temperature blend door linkage to make sure it has appropriate placement and free movement without damage. You may simply take off the two retaining tabs to handle the linkage when it requires maintenance. To put back the system undo all removal actions keeping unharmed original linkage parts if the kit includes them.

How to service and repair the RH temperature blend door actuator for the Dual-Zone EATC on Lincoln MKX?

Starting to repair or service the RH temperature blend door actuator of the Dual-Zone EATC requires first disconnecting and removing the glove compartment damper along with the glove compartment itself. The service procedure begins by removing the RH lower instrument panel insulator followed by taking out the RH lower floor console trim panel. The service requires disconnecting the electrical connector from the RH temperature blend door actuator while removing those three securing screws. Check the RH temperature blend door linkage for wrong placement as well as binding or damage. The service part kit should lack new linkage sections because the intact linkage requires only a new actuator. Before servicing the linkage the operator should detach the two retaining tabs until removal becomes possible. The process ends with inverse order from uninstallation.

OEM Lincoln MKX Blend Door Actuator

Air Blend Door Actuator

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

8 Blend Door Actuators found

View related parts
Lincoln MKX Door Actuator Part Number: GS7Z-19E616-C
$36.27 MSRP: $56.60
You Save: $20.33 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Motor Assembly; HVAC Air Adjustment Control Motor; HVAC Air Inlet Door Actuator; HVAC Heater Blend Door Actuator; Adjust Motor; Mode Motor; Motor
- Manufacturer Note: Air Inlet (Recirculation)
- Replaces: DG9Z-19E616-C, YH-1907
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2016-2018 Lincoln MKX | Black Label, Premiere, Reserve, Select | 6 Cyl 2.7 L GAS, 6 Cyl 3.7 L GAS
View related parts
Lincoln MKX Temperature Door Actuator Part Number: GS7Z-19E616-B
$29.67 MSRP: $47.11
You Save: $17.44 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Motor Assembly; HVAC Air Inlet Door Actuator; HVAC Blend Door Actuator; HVAC Heater Blend Door Actuator; Adjust Motor; Mode Motor; Motor
- Manufacturer Note: Temperature Control
- Replaces: DG9Z-19E616-A, YH-1905
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2016-2018 Lincoln MKX | Black Label, Premiere, Reserve, Select | 6 Cyl 2.7 L GAS, 6 Cyl 3.7 L GAS
View related parts
Lincoln MKX Blower Motor Part Number: GS7Z-19E616-A
$64.59 MSRP: $102.56
You Save: $37.97 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Motor Assembly; HVAC Defrost Mode Door Actuator; HVAC Floor Mode Door Actuator; HVAC Heater Blend Door Actuator; Door Actuator; Adjust Motor; Mode Motor; Motor; Actuator
- Manufacturer Note: Mode Control
- Replaces: YH-1906, DG9Z-19E616-B
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2016-2018 Lincoln MKX | Black Label, Premiere, Reserve, Select | 6 Cyl 2.7 L GAS, 6 Cyl 3.7 L GAS
View related parts
Lincoln MKX Mode Motor Part Number: 7T4Z-19E616-D
$57.88 MSRP: $97.00
You Save: $39.12 (41%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Motor Assembly; HVAC Defrost Mode Door Actuator; HVAC Air Inlet Door Actuator
- Manufacturer Note: Defrost/Panel/Floor Door
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2007-2015 Lincoln MKX | Base | 6 Cyl 3.5 L GAS, 6 Cyl 3.7 L GAS
View related parts
Lincoln MKX Mode Motor, Driver Side Part Number: 7T4Z-19E616-B
$52.97 MSRP: $87.16
You Save: $34.19 (40%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Motor Assembly; HVAC Blend Door Actuator, Left; HVAC Blend Door Actuator
- Manufacturer Note: Temperature Blend Door
- Position: Driver Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2007-2015 Lincoln MKX | Base | 6 Cyl 3.5 L GAS, 6 Cyl 3.7 L GAS
View related parts
Lincoln MKX Mode Motor, Passenger Side Part Number: 7T4Z-19E616-C
$55.68 MSRP: $91.62
You Save: $35.94 (40%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Motor Assembly; HVAC Blend Door Actuator, Right
- Manufacturer Note: Temperature Blend Door
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2011-2015 Lincoln MKX | Base | 6 Cyl 3.7 L GAS
View related parts
Lincoln MKX Mode Motor Part Number: 7T4Z-19E616-A
$55.74 MSRP: $93.40
You Save: $37.66 (41%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Motor Assembly; HVAC Air Inlet Door Actuator
- Manufacturer Note: Air Inlet Mode Door
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2007-2011 Lincoln MKX | Base | 6 Cyl 3.5 L GAS, 6 Cyl 3.7 L GAS
View related parts
Lincoln MKX Mode Motor Part Number: CT4Z-19E616-A
$68.77 MSRP: $109.20
You Save: $40.43 (38%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Motor And Linkage Assembly; HVAC Air Inlet Door Actuator
- Manufacturer Note: Air Inlet Mode Door
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2012-2015 Lincoln MKX | Base | 6 Cyl 3.7 L GAS

Lincoln MKX Blend Door Actuator

OEM Blend Door Actuator boasts unmatched quality. Each part goes through full quality checks. They adhere to Lincoln's official factory standards. These steps remove flaws and inconsistencies. So you can get Blend Door Actuator with long life and a perfect fit. Come to our website and find genuine Lincoln MKX parts. We keep a wide inventory of OEM MKX parts at the highly affordable prices. It's easy to search, compare, and pick what you need. You'll love the clear info and simple checkout. We offer top-rated customer service, and we reply fast. We also ship promptly to ensure your order arrives on time.

The Lincoln MKX Blend Door Actuator makes up a core element in Lincoln MKX HVAC systems since it delivers both reliability and performance excellence. The electric motor controls airflow across different vents to regulate hot and cold air delivery thus maintaining cabin temperatures. Both efficiency and safety receive enhancement through the Lincoln MKX Blend Door Actuator because it stops unneeded warm air from entering the cabin. This actuator functions with multiple MKX models while it delivers the exceptional comfort quality Lincoln vehicles have always provided. The air temperature and airflow direction suffers considerable damage when the Blend Door Actuator suffers from malfunction thus demonstrating its vital role in climate control systems. The Lincoln MKX depends heavily on the Blend Door Actuator to produce excellent performance since this actuator delivers both luxury features and quality components. This actuator provides precise air distribution control as one of its special features so that drivers experience enhanced driving comfort. The popularity of Lincoln MKX as a luxury crossover SUV depends heavily on the reliable performance of its Blend Door Actuator. This advanced design of the the automaker model Blend Door Actuator distinguishes itself in the automotive market by providing reliable comfort and safety to occupants during their journeys.

Lincoln MKX Blend Door Actuator Parts and Q&A

Mode Motor, Driver Side
7T4Z-19E616-B
Q: How to service the LH temperature blend door actuator on Lincoln MKX?
A:
You start service of the LH temperature blend door actuator by taking out the two lower bolts from the steering column opening cover and detaching the cover. Take the in-vehicle temperature sensor aspirator hose and electrical connector off before moving the instrument panel wire harness aside from the actuator. Before lifting the actuator remove three screws holding the LH temperature blend door actuator plus disconnect its power link. Evaluate the LH temperature blend door linkage to make sure it has appropriate placement and free movement without damage. You may simply take off the two retaining tabs to handle the linkage when it requires maintenance. To put back the system undo all removal actions keeping unharmed original linkage parts if the kit includes them.
Mode Motor
7T4Z-19E616-D
Q: How to service and repair the RH temperature blend door actuator for the Dual-Zone EATC on Lincoln MKX?
A:
Starting to repair or service the RH temperature blend door actuator of the Dual-Zone EATC requires first disconnecting and removing the glove compartment damper along with the glove compartment itself. The service procedure begins by removing the RH lower instrument panel insulator followed by taking out the RH lower floor console trim panel. The service requires disconnecting the electrical connector from the RH temperature blend door actuator while removing those three securing screws. Check the RH temperature blend door linkage for wrong placement as well as binding or damage. The service part kit should lack new linkage sections because the intact linkage requires only a new actuator. Before servicing the linkage the operator should detach the two retaining tabs until removal becomes possible. The process ends with inverse order from uninstallation.
