How to Service and Repair the Lower Control Arm on Lincoln LS?

Begin the lower control arm service by checking the vehicle is level on the ground then measuring from hub center to fender lip to set curb height. Use NEUTRAL gear to lift and take off the disc from the rear brake system. To disassemble the shock absorber assembly from the lower arm you need to remove and throw away the metal lower bolt. Driving tools that use compressed air may harm the boot component. Apply the hex-holder device to stop the bar stabilizer linkjoint from rotating during lower link nut removal. Dispose of this nut afterward. Lift the vehicle into NEUTRAL position and disconnect the lower arm by removing and discarding its lower arm-to-wheel knuckle bolt before taking off the lower arm-to-subframe bolts. Place the new lower arm onto the subframe before inserting and positioning new lower arm-to-subframe bolts and nuts that will not be tightened yet. Insert the lower arm into the wheel knuckle while tightening a new bolt and nut to 150 Nm (111 ft. lbs.). Stick to torque tools rather than air tools to stop damage to the boot. You can install the lower stabilizer bar link with the hex-holding tool and secure it at 35 ft. lbs (48 Nm). Use a new lower bolt to secure the shock absorber and spring assembly to the lower arm and tighten it to 133 Nm (98 feet-pounds). Position the jack stand under the suspension until the measurement between hub center and fender lip reaches the curb height target and tighten the lower arm-to-subframe bolts to 175 Nm (129 ft. lbs.) using both bolts. End the work by lowering the suspension then placing back the rear brake disc while the jack stand stays put.

OEM Lincoln LS Control Arm

Suspension Arm

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

12 Control Arms found

View related parts
Lincoln LS Upper Control Arm, Front Passenger Side
Part Number: 6W4Z-3084-AA
$171.28 MSRP: $281.82
You Save: $110.54 (40%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Arm Assembly - Front Suspension; Front Right Upper Control Arm and Ball Joint Assembly.; Suspension Control Arm; Control Arm
- Position: Front Upper Passenger Side
- Replaces: 4W4Z-3084-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2000-2006 Lincoln LS | Appearance, Base, LSE, Luxury, Premium, Sport, Ultimate | 6 Cyl 3.0 L GAS, 8 Cyl 3.9 L GAS
View related parts
Lincoln LS Lower Control Arm, Rear Driver Side
Part Number: 6W4Z-5A649-B
Product Specifications
- Other Name: Arm Assembly - Rear Suspension; Suspension Control Arm, Rear Left Lower; Control Arm
- Position: Rear Lower Driver Side
- Replaces: 6W4Z-5A649-AB, 3W4Z-5A649-ZZ
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2003-2006 Lincoln LS | Appearance, Base, LSE, Luxury, Premium, Sport, Ultimate | 6 Cyl 3.0 L GAS, 8 Cyl 3.9 L GAS
View related parts
Lincoln LS Lower Control Arm, Rear Passenger Side
Part Number: 6W4Z-5A649-A
Product Specifications
- Other Name: Arm Assembly - Rear Suspension; Suspension Control Arm, Rear Right Lower; Control Arm
- Position: Rear Lower Passenger Side
- Replaces: 3W4Z-5A649-AA, 6W4Z-5A649-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2003-2006 Lincoln LS | Appearance, Base, LSE, Luxury, Premium, Sport, Ultimate | 6 Cyl 3.0 L GAS, 8 Cyl 3.9 L GAS
View related parts
Lincoln LS Upper Control Arm, Rear Driver Side
Part Number: 6W4Z-5500-AB
Product Specifications
- Other Name: Arm Assembly - Rear Suspension; Rear Left Upper Control Arm and Ball Joint Assembly.; Suspension Control Arm; Control Arm
- Position: Rear Upper Driver Side
- Replaces: 2W4Z-5500-ZZ
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2000-2006 Lincoln LS | Appearance, Base, LSE, Luxury, Premium, Sport, Ultimate | 6 Cyl 3.0 L GAS, 8 Cyl 3.9 L GAS
View related parts
Lincoln LS Upper Control Arm, Rear Passenger Side
Part Number: 6W4Z-5500-AA
Product Specifications
- Other Name: Arm Assembly - Rear Suspension; Rear Right Upper Control Arm and Ball Joint Assembly.; Suspension Control Arm; Control Arm
- Position: Rear Upper Passenger Side
- Replaces: 2W4Z-5500-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2000-2006 Lincoln LS | Appearance, Base, LSE, Luxury, Premium, Sport, Ultimate | 6 Cyl 3.0 L GAS, 8 Cyl 3.9 L GAS
View related parts
Lincoln LS Upper Control Arm, Front Driver Side
Part Number: 6W4Z-3085-AA
Product Specifications
- Other Name: Arm Assembly - Front Suspension; Front Left Upper Control Arm and Ball Joint Assembly.; Suspension Control Arm; Control Arm
- Position: Front Upper Driver Side
- Replaces: 4W4Z-3085-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2000-2006 Lincoln LS | Appearance, Base, LSE, Luxury, Premium, Sport, Ultimate | 6 Cyl 3.0 L GAS, 8 Cyl 3.9 L GAS
View related parts
Lincoln LS Lower Control Arm, Rear Driver Side
Part Number: XW4Z-5A649-ZZ
Product Specifications
- Other Name: Arm Assembly - Rear Suspension; Suspension Control Arm, Rear Left Lower; Suspension Control Arm; Control Arm
- Position: Rear Lower Driver Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2000-2002 Lincoln LS | Base, LSE | 6 Cyl 3.0 L GAS, 8 Cyl 3.9 L GAS
View related parts
Lincoln LS Lower Control Arm, Rear Passenger Side
Part Number: XW4Z-5A649-AA
Product Specifications
- Other Name: Arm Assembly - Rear Suspension; Suspension Control Arm, Rear Right Lower; Suspension Control Arm; Control Arm
- Position: Rear Lower Passenger Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2000-2002 Lincoln LS | Base, LSE | 6 Cyl 3.0 L GAS, 8 Cyl 3.9 L GAS
View related parts
Lincoln LS Lower Control Arm, Front Driver Side
Part Number: 6W4Z-3079-AA
Product Specifications
- Other Name: Arm Assembly - Front Suspension; Suspension Control Arm; Control Arm
- Manufacturer Note: 16MM Ball-Joint Stud Hole
- Position: Front Driver Side
- Replaces: 4W4Z-3079-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2000-2006 Lincoln LS | Appearance, Base, LSE, Luxury, Premium, Sport, Ultimate | 6 Cyl 3.0 L GAS, 8 Cyl 3.9 L GAS
View related parts
Lincoln LS Lower Control Arm, Front
Part Number: 2W4Z-3079-AA
Product Specifications
- Other Name: Arm Assembly - Front Suspension; Suspension Control Arm; Control Arm
- Manufacturer Note: 16MM Ball-Joint Stud Hole
- Position: Front
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2001-2002 Lincoln LS | Base, LSE | 6 Cyl 3.0 L GAS, 8 Cyl 3.9 L GAS
View related parts
Lincoln LS Lower Control Arm, Front
Part Number: 2W4Z-3078-AA
Product Specifications
- Other Name: Arm Assembly - Front Suspension; Suspension Control Arm; Control Arm
- Manufacturer Note: 16MM Ball-Joint Stud Hole
- Position: Front
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2001-2002 Lincoln LS | Base, LSE | 6 Cyl 3.0 L GAS, 8 Cyl 3.9 L GAS
View related parts
Lincoln LS Lower Control Arm, Front Passenger Side
Part Number: 6W4Z-3078-AA
Product Specifications
- Other Name: Arm Assembly - Front Suspension; Suspension Control Arm; Control Arm
- Manufacturer Note: 16MM Ball-Joint Stud Hole
- Position: Front Passenger Side
- Replaces: 4W4Z-3078-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2000-2006 Lincoln LS | Appearance, Base, LSE, Luxury, Premium, Sport, Ultimate | 6 Cyl 3.0 L GAS, 8 Cyl 3.9 L GAS

Lincoln LS Control Arm

Welcome to our website where you can discover high-quality, genuine Lincoln LS Control Arm. We offer an extensive inventory of OEM Lincoln LS Control Arm at affordable prices. We are committed to providing top-rated customer service along with prompt delivery.

Lincoln LS Control Arm Parts Questions & Experts Answers

Lower Control Arm, Rear Passenger Side
6W4Z-5A649-A
Q: How to Service and Repair the Lower Control Arm on Lincoln LS?
A: Begin the lower control arm service by checking the vehicle is level on the ground then measuring from hub center to fender lip to set curb height. Use NEUTRAL gear to lift and take off the disc from the rear brake system. To disassemble the Shock Absorber assembly from the lower arm you need to remove and throw away the metal lower bolt. Driving tools that use compressed air may harm the boot component. Apply the hex-holder device to stop the bar stabilizer linkjoint from rotating during lower link nut removal. Dispose of this nut afterward. Lift the vehicle into NEUTRAL position and disconnect the lower arm by removing and discarding its lower arm-to-wheel knuckle bolt before taking off the lower arm-to-subframe bolts. Place the new lower arm onto the subframe before inserting and positioning new lower arm-to-subframe bolts and nuts that will not be tightened yet. Insert the lower arm into the wheel knuckle while tightening a new bolt and nut to 150 Nm (111 ft. lbs.). Stick to torque tools rather than air tools to stop damage to the boot. You can install the lower stabilizer bar link with the hex-holding tool and secure it at 35 ft. lbs (48 Nm). Use a new lower bolt to secure the shock absorber and spring assembly to the lower arm and tighten it to 133 Nm (98 feet-pounds). Position the jack stand under the suspension until the measurement between hub center and fender lip reaches the curb height target and tighten the lower arm-to-subframe bolts to 175 Nm (129 ft. lbs.) using both bolts. End the work by lowering the suspension then placing back the rear Brake Disc while the jack stand stays put.
